MV SWITCHGEAR
INCOMING PANEL
An 11kV Incoming Panel equipped with Vacuum Circuit Breaker, Protection Relays and other auxiliary equipment is used to connect 11kV Switchgear to the Power Transformers 20/26MVA and 40MVA.
OUTGOING PANEL
An 11kV Outgoing Panel equipped with Vacuum Circuit Breaker, Protection Relays and other auxiliary equipment is used to connect Grid Station supply to the 11kV Distribution Feeder.
BUS-COUPLER PANEL
An 11kV Bus-Coupler Panel equipped with Vacuum Circuit Breaker, Load Break Switch and other auxiliary equipment is used to connect two 11kV Incoming Panels, where two Power Transformer are installed and Grid Station.
CAPACITOR CONTROL PANEL
An 11kV Capacitor Control Panel equipped with Vacuum Circuit Breaker, Protection Relays and other auxiliary equipment is used to provide automatic switching for the capacitor banks placed at Grid Station.
CONSUMER PANEL
An 11kV Consumer panel equipped with Vacuum Circuit Breaker, Protection Relays and other auxiliary equipment is used to provide independent feeder of 11kV from Grid Station to consumer through an express or dedicated Supply line.
INDUSTRIAL PANEL
An 11kV Industrial Panel equipped with Vacuum Circuit Breaker, Protection Relays and other auxiliary equipment is used to provide 11kV supply to individual consumer (Industry, Mills, Shopping Malls etc.)
